Electric telescopic cantilever shelves

Classification :

The product can be matched with laser cutting machines, shearing machines, cutting machines, and other metal processing industries. The product is widely used in military enterprises, electronic appliances, mechanical manufacturing, medicine and health, logistics distribution, automobiles, food, railways, petrochemicals, textiles and other fields, and is deeply welcomed by users.

+86 13205415081

E-mail

lily@sdconstantstorage.com

RELATED PRODUCTS

ONLINE MESSAGE

Keywords:

Electric Telescopic Cantilever Shelves

Electric telescopic cantilever shelves
Item	Standard				Customized
Storage Sheet Size	6000mm	6000mm	9000mm	12000mm	Customized
Loading Per layer	2tons	3tons	5tons	6tons	Customized
Number of layers	3+1	4+1	3+1	3+1	Customized
Single /Double	Single	Double	Double	Double	Customized
Total Loading per rack	8tons	25tons	35tons	42tons	Customized
Length of Arm	550mm	600mm	800mm	800mm	Customized
Distance between two layers	600mm	600mm	800mm	800mm	Customized
Operation System	PLC Frequency conversion control	PLC Frequency conversion control	PLC Frequency conversion control	PLC Frequency conversion control	PLC Frequency conversion control
Color of Rack	Orange/Blue	Orange/Blue	Orange/Blue	Orange/Blue	Customized

Roll out cantilever racking is ideal for storing and accessing bar stock, angle iron, tube,pipe, rollers, mandrels..etc long material and bulk goods, usually work will take a lot of time and find the right items they need if these items are stored on the ground. Roll out racks will increase your work efficiency and save your warehouse space.

Features:

1.Material is handled by crane, no necessary with wider aisles so save space.

2.Sorting and storing any length of material.

3.Time-saving, material can be operated by crane from rack to terminal directly.

4.Solid structure with heavy loading capacity loading Max 5000kgs per layer.

5.100% extended arms, each layers can be accessed easily.

6.Materials can be stored by categories or size, and tray available for leftovers

7.Single or Double units available (Customized dimension)

8.Electrically Drive roll out racking available.

Customer visit

Constantstorage has always been adhering to the market-centric approach to meet customer requirements to the maximum extent, and the business philosophy of "creating brands with heart and gaining reputation with sincerity". It provides customers with high-quality products and services with rigorous military quality, professionalism, and excellence, and has won unanimous praise in the Chinese aerospace, Chinese weapons, Chinese railways, automobile manufacturing, engineering machinery, non-ferrous metal titanium alloy and other industries.

Electric Telescopic Cantilever Shelves
